3.2×2.0mm Square rectangular indicator light Blue led emitting diode Blue Diffused short pin Dip lamp led for cars

Product Categories
DOUBLE LIGHT ELECTRONICS TECHNOLOGY CO.,LTD
Contact Now

3.2×2.0mm Square rectangular indicator light Blue led emitting diode Blue Diffused short pin Dip lamp led for cars

Brand Name : Double Light

Model Number : DL-234BD-1B70

Certification : ISO9001:2008,Rosh

Place of Origin : China

MOQ : 1000 PCS

Payment Terms : L/C, T/T, Western Union, Paypal

Supply Ability : 15,000,000pcs per Day

Delivery Time : 5-7 working days after received your payment

Packaging Details : Dimensions per Unit:0.28 × 0.2 × 0.13 Meters • Weight per Unit:3.5 Kilograms • Units per Export Carton:40000 • Export Carton Dimensions L/W/H: 0.45 × 0.28 × 0.27 Meters • Export Carton Weight:14.2 Kilograms

Product Name : Square rectangular indicator LED

Power (mW) : 95

Emitted Color : Blue

Lens Color : Blue Diffused

Peak Emission Wavelength : 468nm

Forward Voltage @20ma : 2.8-3.3

Viewing Angle : 70 Deg

Luminous Intensitysity : 350-550mcd

Contact Now

2*3*4mm Square LED long pin short pin blue rectangular LED indicator led diode

Part No. Chip Material Lens Color Source Color
DL-234BD-1B70 InGaN Blue Diffused Blue
  • Features:
  1. Choice of various colors.
  2. 3.2×2mm Rectangular.
  3. Available on tape and reel.
  4. Reliable and robust.
  5. The product itself will remain within RoHS compliant Version.
  • Descriptions:
  1. The series is specially designed for applications requiring higher brightness.
  2. The LED lamps are available with different colors, intensities.
  • Applications:
  1. TV set.
  2. Monitor.
  3. Telephone.
  4. Computer.
  5. Circuit board.
  6. Status indicators.
  7. Commercial use.
  8. Advertising Signs.
  9. Back lighting.

Absolute Maximum Ratings at Ta=25℃

Parameters Symbol Max. Unit
Power Dissipation PD 95 mW

Peak Forward Current

(1/10 Duty Cycle, 0.1ms Pulse Width)

 IFP 100 mA
Forward Current IF 25 mA
Reverse Voltage VR 5 V
Electrostatic Discharge (HBM) ESD 1000 V
Operating Temperature Range Topr -40℃ to +85℃
Storage Temperature Range Tstg -40℃ to +100℃

Lead Soldering Temperature

[4mm (.157″) From Body]

 Tsld 260℃ for 5 Seconds

Electrical Optical Characteristics at Ta=25℃

Parameters Symbol Min. Typ. Max. Unit Test Condition
Luminous Intensity * IV 350 550 --- mcd IF=20mA (Note 1)
Viewing Angle * 2θ1/2 --- 70 --- Deg IF=20mA (Note 2)
Peak Emission Wavelength λp --- 468 --- nm IF=20mA
Dominant Wavelength λd --- 470 --- nm IF=20mA (Note 3)
Spectral Line Half-Width △λ --- 25 --- nm IF=20mA
Forward Voltage VF 2.8 3.3 --- V IF=20mA
Reverse Current IR --- --- 10 µA VR=5V

Notes:

  1. Luminous intensity is measured with a light sensor and filter combination that approximates the CIE eye-response curve.
  2. θ1/2 is the off-axis angle at which the luminous intensity is half the axial luminous intensity.
  3. The dominant wavelength (λd) is derived from the CIE chromaticity diagram and represents the single wavelength which defines the color of the device.
  • Package Dimension:

3.2×2.0mm Square rectangular indicator light Blue led emitting diode Blue Diffused short pin Dip lamp led for cars

Company introduction:

Hongkong Double Light Electronics,and hope we can cooperate with you like our other clients Toshiba,Huawei,Harman International,ACP,ABB,Flextronics etc.
Quality is our culture.Work with us,your money in safe,your business in safe.We will refund you in case of bad quality issue happens due to our product itself.

3.2×2.0mm Square rectangular indicator light Blue led emitting diode Blue Diffused short pin Dip lamp led for cars

More options are available for you.

3.2×2.0mm Square rectangular indicator light Blue led emitting diode Blue Diffused short pin Dip lamp led for cars

Buy Led components, choose long history manufacturer---DOUBLE LIGHT!

Tel: 86-755-82853859
Fax: 86-755-83229774
Email:wendy@doublelight.com.cn
Wechat:ywj199111103964
Skype:wendy@doublelight.com.cn
